Kassow Robots KR810

|
Save
With a payload capacity of 10 kg and a reach of 850 mm, the Kassow Robots KR810 Cobot is a powerful, easy-to-use and compact 7-axis lightweight collaborative robot.
Reach

850 mm

Payload

10 kg

Technical Questions

€29,100.00 excl. VAT.

From 1.000,00 € a month with lease buy or installment.

Learn more
  • Overview
  • Specifications
  • Description
  • Downloads
  • FAQ
  • Similar products

Robot Image

Robot Image

Safe and Reliable

Kassow Robots' cobots have built-in force-torque sensors that detect shocks and abnormal forces. The sensors stop the robot in case of overload.

Robot Image

Speed

Kassow Robots move at speeds up to 225 degrees per second on all 7 axes. Higher robot speeds significantly increase production output and thus expand the range of tasks that can be performed.

Robot Image

Featured on Unchained TV

video-image
Pick & PlaceMetalMechnical Engineering

24/7 automated laser marking with Kassow Robots and OnRobot

video-image
Pick & PlaceMetalMechnical Engineering

Automation of machine operation with Kassow Robots

video-image
Pick & PlaceMechnical EngineeringElectrical Engineering

Collaborative machine operation with the Kassow Robots KR810

Compare

Reach

Payload

Repeatability

Weight

Robot Image

Kassow Robots KR810

€29,100.00 excl. VAT.

850 mm

10 kg

0.1 mm

24 kg

Robot Image

Kassow Robots KR1018

€37,500.00 excl. VAT.

1000 mm

18 kg

0.1 mm

34 kg

Robot Image

Kassow Robots KR1205

€31,500.00 excl. VAT.

1200 mm

5 kg

0.1 mm

25 kg

Robot Image

Kassow Robots KR1410

€37,500.00 excl. VAT.

1400 mm

10 kg

0.1 mm

35 kg

Robot Image

Kassow Robots KR1805

€41,500.00 excl. VAT.

1800 mm

5 kg

0.1 mm

38 kg

Reach

Payload

Repeatability

Weight

Robot Image

Kassow Robots KR810

€29,100.00 excl. VAT.

850 mm

10 kg

0.1 mm

24 kg

Robot Image

AUBO i5

€18,000.00 excl. VAT.

886.5 mm

5 kg

0.05 mm

24 kg

Robot Image

Neuromeka Indy7

€23,400.00 excl. VAT.

1300 mm

7 kg

0.1 mm

28 kg

Robot Image

KUKA LBR iisy 15 R930

€30,915.00 excl. VAT.

930 mm

15 kg

0.05 mm

43.2 kg

In the box

Robot Image

Robot

Robot Image

Teachpanel

Robot Image

Controlbox

Use case combination

Robot Image
Cobot, Kassow Robots

Kassow Robots KR810

€29,100.00 excl. VAT.
+
Robot Image
Finger Grippers, OnRobot

OnRobot 2FG7

€3,862.00 - €5,304.00 excl. VAT.

Research

The KR810 is small, light and robust, making it the perfect cobot for research applications.

€32,962.00

excl. VAT.

Robot Image
Cobot, Kassow Robots

Kassow Robots KR810

€29,100.00 excl. VAT.
+
Robot Image
Finger Grippers, DH Robotics

DH Robotics AG-95

€3,650.00 excl. VAT.
+
Robot Image
Camera, Framos

FRAMOS Industrial Depth Camera D415e Starter Kit

€949.00 excl. VAT.

Education

With its easy-to-use programming environment and intuitive user interface, the KR810 is perfect for training purposes.

€33,699.00

excl. VAT.

Robot Image
Cobot, Kassow Robots

Kassow Robots KR810

€29,100.00 excl. VAT.
+
Robot Image
Finger Grippers, OnRobot

OnRobot RG2-FT

€9,370.00 - €10,812.00 excl. VAT.

Prototyping

The KR810 is the perfect foundation for your prototyping station.

€38,470.00

excl. VAT.

Arm
Reach850 mm
Payload10 kg
Weight24 kg
Performance
Max. linear TCP speed1 m/s
Repeatability0.1 mm
Min. Operating Temperature0 °C
Max. Operating temperature45 °C
Joint Movement (Range: ° / Max Speed : ° /s)
J1-360 till 360±225
J2-70 till 180±225
J3-360 till 360±225
J4-70 till 180±225
J5-360 till 360±225
J6-360 till 360±225
J7-360 till 360±225
Other Features
IP classificationIP54
Noise Level65 dB
Control Box
I/O portsDigitale Ausgänge 24V: 8 / Relaisausgänge: 4 / Digitale Eingänge 3-30V: 16 / Analoge E/A 0-10V: 2/2 / Analoge E/A 4-20mA: 2
Supply voltage100-120 VAC, 200-240 VAC

True to the motto "strong, fast, simple", Kassow Robots develops and produces uniquely efficient lightweight industrial collaborative robots with 7 axes. With maximum payloads of up to 18 kilograms and maximum reaches of up to 1800 millimeters, Kassow Robots' cobots are powerful, fast and suitable for use in small spaces due to their maneuverability. They also enable small and medium-sized enterprises (SMEs) to implement both simple and complex automation flexibly, independently and cost-effectively.
Kassow’s technology is built around their robots’ extraordinarily strong joints. Not only are the joints robust, but they also enable lateral movements thanks to their 7th axis and optimally reproduce the motor function of human arms. This innovation was combined with simple, intuitive programming and operation based on well-known standard tablet technology.
These innovative cobots were developed by a team led by Kassow Robots founder and CEO Kristian Kassow, who has already made a significant mark on the industry with his past contributions to the robotics industry.
