Kassow Robots KR810
850 mm
10 kg
Technical Questions
ROI Calculator
€29,100.00 excl. VAT.
From 1.000,00 € a month with lease buy or installment.
- Overview
- Compare
- In the box
- Use case combination
- Specifications
- Description
- Downloads
- FAQ
- Similar products
Safe and Reliable
Kassow Robots' cobots have built-in force-torque sensors that detect shocks and abnormal forces. The sensors stop the robot in case of overload.
Speed
Kassow Robots move at speeds up to 225 degrees per second on all 7 axes. Higher robot speeds significantly increase production output and thus expand the range of tasks that can be performed.
Featured on Unchained TV
24/7 automated laser marking with Kassow Robots and OnRobot
Automation of machine operation with Kassow Robots
Collaborative machine operation with the Kassow Robots KR810
Compare
Reach
Payload
Repeatability
Weight
Kassow Robots KR810
€29,100.00 excl. VAT.
850 mm
10 kg
0.1 mm
24 kg
Kassow Robots KR1018
€37,500.00 excl. VAT.
1000 mm
18 kg
0.1 mm
34 kg
Kassow Robots KR1205
€31,500.00 excl. VAT.
1200 mm
5 kg
0.1 mm
25 kg
Kassow Robots KR1410
€37,500.00 excl. VAT.
1400 mm
10 kg
0.1 mm
35 kg
Kassow Robots KR1805
€41,500.00 excl. VAT.
1800 mm
5 kg
0.1 mm
38 kg
Reach
Payload
Repeatability
Weight
Kassow Robots KR810
€29,100.00 excl. VAT.
850 mm
10 kg
0.1 mm
24 kg
AUBO i5
€18,000.00 excl. VAT.
886.5 mm
5 kg
0.05 mm
24 kg
Neuromeka Indy7
€23,400.00 excl. VAT.
1300 mm
7 kg
0.1 mm
28 kg
KUKA LBR iisy 15 R930
€30,915.00 excl. VAT.
930 mm
15 kg
0.05 mm
43.2 kg
In the box
Robot
Teachpanel
Controlbox
Use case combination
Kassow Robots KR810
OnRobot 2FG7
Research
The KR810 is small, light and robust, making it the perfect cobot for research applications.
€32,962.00
excl. VAT.
Kassow Robots KR810
DH Robotics AG-95
FRAMOS Industrial Depth Camera D415e Starter Kit
Education
With its easy-to-use programming environment and intuitive user interface, the KR810 is perfect for training purposes.
€33,699.00
excl. VAT.
Kassow Robots KR810
OnRobot RG2-FT
Prototyping
The KR810 is the perfect foundation for your prototyping station.
€38,470.00
excl. VAT.
| Arm | ||
|---|---|---|
| Reach | 850 mm | |
| Payload | 10 kg | |
| Weight | 24 kg | |
| Performance | ||
|---|---|---|
| Max. linear TCP speed | 1 m/s | |
| Repeatability | 0.1 mm | |
| Min. Operating Temperature | 0 °C | |
| Max. Operating temperature | 45 °C | |
| Joint Movement (Range: ° / Max Speed : ° /s) | ||
|---|---|---|
| J1 | -360 till 360 | ±225 |
| J2 | -70 till 180 | ±225 |
| J3 | -360 till 360 | ±225 |
| J4 | -70 till 180 | ±225 |
| J5 | -360 till 360 | ±225 |
| J6 | -360 till 360 | ±225 |
| J7 | -360 till 360 | ±225 |
| Other Features | ||
|---|---|---|
| IP classification | IP54 | |
| Noise Level | 65 dB | |
| Control Box | ||
|---|---|---|
| I/O ports | Digitale Ausgänge 24V: 8 / Relaisausgänge: 4 / Digitale Eingänge 3-30V: 16 / Analoge E/A 0-10V: 2/2 / Analoge E/A 4-20mA: 2 | |
| Supply voltage | 100-120 VAC, 200-240 VAC | |
True to the motto "strong, fast, simple", Kassow Robots develops and produces uniquely efficient lightweight industrial collaborative robots with 7 axes. With maximum payloads of up to 18 kilograms and maximum reaches of up to 1800 millimeters, Kassow Robots' cobots are powerful, fast and suitable for use in small spaces due to their maneuverability. They also enable small and medium-sized enterprises (SMEs) to implement both simple and complex automation flexibly, independently and cost-effectively.
Kassow’s technology is built around their robots’ extraordinarily strong joints. Not only are the joints robust, but they also enable lateral movements thanks to their 7th axis and optimally reproduce the motor function of human arms. This innovation was combined with simple, intuitive programming and operation based on well-known standard tablet technology.
These innovative cobots were developed by a team led by Kassow Robots founder and CEO Kristian Kassow, who has already made a significant mark on the industry with his past contributions to the robotics industry.
Did not find what you’re looking for?
To place an order, send us an inquiry through the button at the top of the page or contact us through the chat.
Unchained Robotics is the biggest marketplace for all things automation. We have over 36 brands with 9 different categories such as Cobots, Grippers, Cameras, Starter-kits, End-of-Arm-Accessories, Teaching-kits, Turnkey Solution, Cobot-Base and even
Services. For more information, check out our About page.
