DOBOT Nova 2

|
Save
The DOBOT Nova 2 is a modern cobot with a payload of 2 kg, a reach of 625 mm and a repeatability of 0.05 mm. The Nova 2 was developed specifically for retail tasks and can, for example, carry out tasks such as preparing coffee, tea or various dishes. Thanks to its interchangeable covers, the cobot can be visually adapted to a wide variety of shop concepts.
Reach

625 mm

Payload

2 kg

Technical Questions

€6,650.00 excl. VAT.

From 700,00 € a month with lease buy or installment.

Lease & buy guide
  • Specifications
  • Overview
  • Description
  • Downloads
  • FAQ
  • Similar products

Featured on Unchained TV

Unfortunately, there are no use case videos yet for this product.
Browse other robotics videos on Unchained TV.

Compare

Reach

Payload

Repeatability

Weight

Robot Image
DOBOT CR10A

€21,100.00 excl. VAT.

1300 mm

10 kg

0.03 mm

40 kg

Robot Image
DOBOT CR12A

€23,100.00 excl. VAT.

1200 mm

12 kg

0.03 mm

39.5 kg

Robot Image
DOBOT CR16A

€23,900.00 excl. VAT.

1000 mm

16 kg

0.03 mm

40 kg

Reach

Payload

Repeatability

Weight

Arm
Reach625 mm
Payload2 kg
Weight11 kg

Performance
Max. linear TCP speed1.6 m/s
Repeatability0.05 mm
Min. Operating Temperature0 °C
Max. Operating temperature50 °C
I/O PortsDigital in: 2x

Joint Movement (Range: ° / Max Speed : ° /s)
J1-360 till 360±135
J2-180 till 180±135
J3-156 till 156±135
J4-360 till 360±135
J5-360 till 360±135
J6-360 till 360±135
J7 --

Other Features
IP classificationIP54
Noise Level65 dB
Mounting DirectionAll directions

Control Box
Dimension220 x 150 x 45 mm
Weight1.2 kg
I/O portsDigital in: 16x
Digital out: 16x
Analog in: 2x
Analog out: 2x
I/O power supply24V, Max 2A
CommunicationNetwork: 2x (for TCP/IP and Modbus TCP communication
USB: 2x
485 interface: 1x for RS485 and Modbus RTU communication
IP classificationIP20

The DOBOT Nova 2 sets new standards in the world of cobots, offering a payload of 2 kg and a reach of 625 mm. This ultra-lightweight and user-friendly cobot is specifically designed for use in the retail sector and requires just 1 m² of space, making it ideal for shops of all sizes.

With its compact control box and the option to customise the outer casing, the Nova 2 blends seamlessly into any shop layout without the need for extensive modifications. It is particularly well-suited to applications in sectors such as the catering industry and many other commercial settings.

One of the Nova 2’s greatest strengths is its ease of use. Thanks to innovative programming methods such as the playback of user-guided paths and an intuitive graphical user interface, even users with no prior technical knowledge can quickly integrate the cobot into their workflows. Monitoring of the cobot’s activities and software updates is conveniently carried out via the cloud.

The DOBOT Nova 2 also sets new standards in terms of safety. Equipped with intelligent sensors featuring five adjustable safety levels, it guarantees maximum safety. In the event of a collision, the cobot stops within just 0.01 seconds. Additional safety features, such as the detection of human movement and the freezing of its position in the event of a power cut, underline the commitment to safe human-robot collaboration.
