DOBOT Nova 2
625 mm
2 kg
Technical Questions
ROI Calculator
€8,920.00 excl. VAT.
From 900,00 € a month with lease buy or installment.
- Overview
- Compare
- Specifications
- Description
- Downloads
- FAQ
- Similar products
Featured on Unchained TV
Unfortunately, there are no use case videos yet for this product. Click here to watch other videos on Unchained TV.
Compare
Reach
Payload
Repeatability
Weight
DOBOT Nova 2
€8,920.00 excl. VAT.
625 mm
2 kg
0.05 mm
11 kg
DOBOT CR10
€21,540.00 excl. VAT.
1300 mm
10 kg
0.03 mm
39 kg
DOBOT CR10A
€25,970.00 excl. VAT.
1300 mm
10 kg
0.03 mm
40 kg
DOBOT CR12A
€26,930.00 excl. VAT.
1200 mm
12 kg
0.03 mm
39.5 kg
Reach
Payload
Repeatability
Weight
DOBOT Nova 2
€8,920.00 excl. VAT.
625 mm
2 kg
0.05 mm
11 kg
AUBO i5
€18,000.00 excl. VAT.
886.5 mm
5 kg
0.05 mm
24 kg
Doosan Robotics A0912
€27,500.00 excl. VAT.
1200 mm
9 kg
0.05 mm
27 kg
Universal Robots UR16e
€41,423.00 excl. VAT.
900 mm
16 kg
0.05 mm
33.1 kg
| Arm | ||
|---|---|---|
| Reach | 625 mm | |
| Payload | 2 kg | |
| Weight | 11 kg | |
| Performance | ||
|---|---|---|
| Max. linear TCP speed | 1.6 m/s | |
| Repeatability | 0.05 mm | |
| Min. Operating Temperature | 0 °C | |
| Max. Operating temperature | 50 °C | |
| I/O Ports | Digital in: 2x | |
| Joint Movement (Range: ° / Max Speed : ° /s) | ||
|---|---|---|
| J1 | -360 till 360 | ±135 |
| J2 | -180 till 180 | ±135 |
| J3 | -156 till 156 | ±135 |
| J4 | -360 till 360 | ±135 |
| J5 | -360 till 360 | ±135 |
| J6 | -360 till 360 | ±135 |
| J7 | - | - |
| Other Features | ||
|---|---|---|
| IP classification | IP54 | |
| Noise Level | 65 dB | |
| Mounting Direction | All directions | |
| Control Box | ||
|---|---|---|
| Dimension | 200 x 120 x 55 mm | |
| Weight | 1.3 kg | |
| I/O ports | Digital in: 8x Digital out: 8x Analog in: 2x Analog out: 2x | |
| I/O power supply | 24V, Max 2A | |
| Communication | Network: 2x (For TCP/IP and Modbus TCP communication USB: 2x 485 Interface: 1x For RS485 and Modbus RTU communication | |
| IP classification | IP20 | |
The DOBOT Nova 2 sets new standards in the world of cobots with a payload of 2 kg and a reach of 625 mm. This ultra-light and user-friendly cobot is specially designed for retail use and requires only 1 square metre of space, making it ideal for shops of all sizes.
With its handy control box and the ability to customise the outer shell, the Nova 2 fits seamlessly into any shop layout without the need for extensive customisation. It is particularly suitable for applications in areas such as catering and many other commercial applications.
One of the Nova 2's greatest strengths is its ease of use. Thanks to innovative programming methods such as user-guided path replay and an intuitive graphical user interface, even users with no prior technical knowledge can quickly integrate the cobot into their workflows. Cobot activities and software updates are monitored conveniently via the cloud.
The DOBOT Nova 2 also sets new standards in terms of safety. Equipped with intelligent sensors with five adjustable protection levels, it guarantees maximum safety. In the event of a collision, the cobot stops within just 0.01 seconds. Additional safety functions such as recognising human movements and freezing the posture in the event of a power failure underline the commitment to safe human-robot collaboration.
