GRIP SHW Connector

|
Save
With the GRIP SHW, you can connect and disconnect tools and grippers in just seconds. The SHW connector is a newly developed tool changing system with an optimized locking mechanism.

The connector consists of a shear bolt that clamps the upper part and lower part. During locking, the lower part is tightened by the locking stroke. Additionally, by mounting a centering disk, the changing system is centered on the robot and/or tool side. Mounting is possible in the upper part (on the robot side) and lower part (on the tool side).

You can find out exactly which parts are included in each GRIP SHW kit in the download section.
Reset

Technical Questions

€1,098.50 - €2,339.50 excl. VAT.

From 200,00 € a month with lease buy or installment.

Learn more
  • Overview
  • Description
  • Downloads
  • FAQ
  • Similar products

Precise

High repeatability < 0.02 mm

Intuitive

Can be opened and closed with one handle, requires no tools

Universal

Compatible with all common tools and grippers

Flexible

Pneumatic and electrical feedthroughs available for some models

Inhalt des Sets

  • 1 x SHW Oberteil  
  • 2 x SHW Unterteil

Inhalt des optionalen elektrischen Kupplungssatzes

Nur für bestimmte Größen verfügbar: 1 x elektrische Kupplung Oberteil, 2 x elektrische Kupplung Unterteil

Inhalt des optionalen elektropneumatischen Kupplungssatzes

Nur für bestimmte Größen verfügbar: 1 x elektropneumatische Kupplung - Oberteil, 2 x elektropneumatische Kupplung - Unterteil

Featured on Unchained TV

Unfortunately, there are no use case videos yet for this product.
Click here to watch other videos on Unchained TV.

With the GRIP SHW Connector, you create almost infinite connection possibilities with different tools. Easily connect and change grippers, polishing tools, welding heads, dispensing tools,  calibration tips, and more via quick intuitive operation. It's easy to install and even easier to use.

Each GRIP SHW Connector is equipped with counterbores for direct mounting. The size and position of the counterbores is adapted to DIN EN ISO 9409-1. The GRIP SHW Connector offers one simple connection  and a thousand possibilities.

GRIP offers a wide range of SHW models with a wide array of sizes and connections available. There's a GRIP SHW for almost all applications!

  • Interface according to DIN EN ISO 9409-1
  • High repeatability < 0.02 mm
  • Withstands 5,000 cycles
  • Withstands high loads despite its own low weight
  • No tools required thanks to an integrated operating lever
  • Improved operating lever with a simple folding motion
  • Intuitive operation: can be released and closed with a single hand movement
  • Lightweight, anodized high-strength aluminum
  • Integrated mounting surface for energy feedthrough
  • Locking bolt protects the hand lever from unintentional release

To place an order, send us an inquiry through the button at the top of the page or contact us through the chat.
